EL34C, Classic Series, Psvane Vacuum Tube, Apex Matched Pair, Power

USD 56.90 USD

SKU: MdOl3wXE

Brand: Apex Matched

MPN: T-EL34-C-PSV-MP

GTIN: Does Not Apply

Condition: New

Tags: ±100 V 0 V 0.5 MΩ 0.7 MΩ 1.0 PF 1.1 PF 1.5 A 10 pF 100 mA 100 V 11 mA/V 115 mm 12.2 V 15 kΩ 15.2 PF 150 mA 25 W 250 ℃ 250 V 33.5 mm 500 V 6.3 V 8 W 8.4 PF 800 V Any Apex Matched Octal PSVANE EL34C T-EL34-C-PSV-MP Unknown Vacuum Tube

Categories: Vintage Electronics

Specifications

Brand	Apex Matched
Amplifier Type	Unknown
Base	Octal
UH	6.3 V
IH	1.5 A
Max. Ua	800 V
Max. Ug2	500 V
Max. Ug1	-100 V
Max. Pa	25 W
Max. Pg2	8 W
Max. Ik	150 mA
Rg1 With Cathode Bias	0.7 MΩ
Rg1 With Fixed Bias	0.5 MΩ
Rg1 Uh-k	±100 V
Rg1 Tbulb	250 ℃
Input Capacitance	15.2 PF
Output Capacitance	8.4 PF
Grid To Plate Capacitance	1.1 PF
Grid To Filament Capacitance	1.0 PF
Cathode To Filament Capacitance	10 PF
Typ. Ua	250 V
Typ. Ug2	250 V
Typ. Ug3	0 V
Typ. -Ug1	12.2 V
Typ. Ia	100 mA
Typ. Gm	11 mA/V
Typ. Ri	15 kΩ
Total Height	115 mm
Bulb Width	33.5 mm
Type	Vacuum Tube
MPN	T-EL34-C-PSV-MP
Compatible Brand	Any
Compatible Model	Any

These tubes are matched using Apex Tube Matching®. Bulb Width 33.5 mm. Grid to plate Capacitance 1.1 PF. Product Details. Gm 11 mA/V. -Ug1 12.2 V. Total Height 115 mm. Rg1 With fixed bias 0.5 MΩ.

EL34C, Classic Series, Psvane Vacuum Tube, Apex Matched Pair, Power
