Matched QUAD 6P14P-ER /EL84/7189/ TUBES TESTED WITH ROETEST BY CURVES. NOS/NIB
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Model | Matched QUAD 6P14P-ER |
| Country/Region Of Manufacture | Russian Federation |
| Tube Type | Vacuum Tubes |
| Product Type | Tubes |
| Type | NOS Tube |
| MPN | Does Not Apply |
| Brand | Russian Military |
Matched OCTET 6P14P-ER /EL84/7189/ TUBES TESTED WITH ROETEST BY CURVES. NOS/NIB6P14P-ER tube pair same date NOS/NIB matched by curves Roetest V10You are looking at a matched pair of NOS 6P14P-ER, best selected by curves using Roetest V10 professional tube testing system, the best tube tester that exists now, a wonderful device. 6P14P-ER is the best variant between all 6p14 and EL84 tubes, a classification ofqualities in ascending order would be 6p14p, 6p14p-k, 6p14p-v, 6p14p-ev, 6p14p-er,ER variant being high reliability, long life an tight specs tube, NOS -from the times when there was no saving for rare metals and precious metals, especially for militaryuse tubes. Each tube contains few mg of pure 24K gold for g1. If you have experience in the field of tubes you can find in the phot SAME DATA 1990!!! Military equipment,"OTK", high reliability. Military quality check passed (rhombus) You are looking at a MATCHED QUAD of NOS 6P14P-ER, best selected by curves using Roetest V10 professional tube testing system, the best tube tester that exists now, a wonderful device. 6P14P-ER is the best variant between all 6p14 and EL84 tubes, a classification of qualities in ascending order would be 6p14p, 6p14p-k, 6p14p-v, 6p14p-ev, 6p14p-er, ER variant being high reliability, long life an tight specs tube, NOS -from the times when there was no saving for rare metals and precious metals, especially for military use tubes. Each tube contains few mg of pure 24K gold for g1. If you have experience in the field of tubes you can find in the photos and in the details below the testing / sorting procedure and all the results, and if you do not have the necessary experience to understand what is explained you can trust that we deliver only very good tubes. The best method of selecting tubes in pairs is to overlap the G1/Ia curves, the superimposed curves show us that the tubes have the same plate current and the same transconductance in the whole operating range. One point matching method used with analog tube testers is a pretty good compromise solution, but identical tubes at one point can have big differences at higher or lower currents, testing in 20÷50 points with these devices and drawing curves take hours for each tube. Roetest does this quickly and with great precision. In addition to the tubes, you will receive an individual data sheet, one A4 page for each tube. The tubes (batch of 200 pcs. same data in original individual boxes and 50 pcs boxes) are tested in a very well equipped laboratory, specialized in tube testing, with very well qualified personnel and with long experience for this. All tube data can be seen in the printing protocol, all tubes meet the manufacturer's datasheet specifications. Before measuring each tube was heated in a separate support for 30 minutes, a shorter heating leads to erroneous results and does not indicate gassy tubes. 6P14P is equivalent to many tubes, all can be seen at the bottom of the printed page (CV8069 etc.). Condition for test: Up=250V, Uscreen=250V, Ug1=-7.3V. For this sorting we accepted only tubes with 2 digits nanoA for Ig1, this means a very good vacuum inside (under 1% Ip modification with 1M2 resistor g1 series), the most important thing that must be tested for NOS tubes. You will get the best tubes selected and the best sorting in pairs that is possible. If you have a sophisticated amp with 1% tolerance components and high quality output transformer, don’t buy tubes at random with +/- 40% tolerance (means possible differences of 80% between tubes). These 80% could be found at new tubes from any producer, even some of them don’t say explicit in their datasheets. Those who use tubes are more familiar with terms like bias, gain (µ), plate current, slope/transconductance, and maybe someone is wondering what the term „D of plate” in the measured data means. Its value in itself is not so important but it is useful to calculate the other parameters taking into account Barkhausen's tubular formula S x D x Ri = 1 (slope * penetration * internal resistance=1), where D is –dUg/dUa at Ia=const. Barkhausen vas a german physicist, he was “the guru” of tubes, his theory and formulas guided the entire period of electronic tubes. 6P14P-ER Name6P14P-ERTypeOutput pentode,hi-durable,long-lifeApplicationLF power amplification in special equipmentCathode typeoxide,indirect heatingEnvelopeglass,miniatureMass,g20Filament voltage,V6,3Filament current,A0,74-0,86Anode voltage,V250Anode current,A0,04-0,056Anode power,W14Grid2 voltage,V250Steepness,mA/V9,5-14,5Reverse grid current,uA0,3Microphnic noise,mV250Gain~20Socket type Please allow for the following shipping times:EU countries: 5-8 business days, on rare occasions a few days more USA: 10-15 business days, on rare occasions more South East Asia (Japan, Singapore, S. Korea, Hong Kong, Taiwan etc) 10 business days, on rare occasions more India, China, Russia, Kazakhstan, Pakistan, Indonesia, Malaysia, Thailand, Australia, South Africa etc: at least 15 business days, but frequently around 25 business days Please note that shipping cost is calculated at average. If you have any objections please contact me for a specific quotation.
